材质 |
| |
塑件： PA66+23%GF,
UL 94V-0 |
| |
端子： |
黄铜，0.8厚
镀锡 |
| |
螺丝： |
钢，M4
镀镍 |
|
|
|
|
| |
性能 |
| |
额定电压/电流： |
300V
/ 20A |
| |
使用温度： |
-4O°C~+105°C |
| |
耐电压： |
AC2000V
/ 1 Min |
| |
绝缘阻抗： |
500MΩ /
DC500V |
| |
适用线径： |
22-12AWG |
| |
最大锁紧扭力： |
1.2N.m
10.6Lb.in |
|
|
极 数
|
2
|
3
|
4
|
5
|
6
|
7
|
8
|
9
|
10
|
|
L(mm)
|
22.16
|
31.66
|
41.16
|
50.66
|
60.16
|
69.66
|
79.16
|
88.66
|
98.16
|
|
S(mm)
|
9.50
|
19.00
|
28.50
|
38.00
|
47.50
|
57.00
|
66.50
|
76.00
|
85.50
|
| |
|
极 数
|
11
|
12
|
13
|
14
|
15
|
16
|
17
|
18
|
19
|
|
L(mm)
|
107.66
|
117.16
|
126.66
|
136.16
|
145.66
|
155.16
|
164.66
|
174.16
|
183.66
|
|
S(mm)
|
95.00
|
104.50
|
114.00
|
123.50
|
133.00
|
142.50
|
152.00
|
161.50
|
171.00
|
| |
|
极 数
|
20
|
21
|
22
|
23
|
24
|
25
|
26
|
27
|
28
|
|
L(mm)
|
193.16
|
202.66
|
212.16
|
221.66
|
231.16
|
240.66
|
250.16
|
|
|
|
S(mm)
|
180.50
|
190.00
|
199.50
|
209.00
|
218.50
|
228.00
|
237.50
|
|
|
|
| |
|
|
