材质 |
| |
塑件： |
PA66 UL
94V-0 |
|
|
端子： |
黄铜，0.7厚
镀锡 |
| |
螺丝： |
钢，M2.5
镀镍 |
|
|
|
|
|
|
性能 |
| |
额定电压/电流： |
300V
/ 10A |
|
|
使用温度： |
-4O°C~+105°C |
| |
耐电压： |
AC2000V
/ Min |
|
|
绝缘阻抗： |
500MΩ /
DC500V |
| |
适用线径： |
22-16AWG |
| |
最大锁紧扭力： |
0.4N.m
3.5Lb.in |
|
|
极 数
|
2
|
3
|
4
|
5
|
6
|
7
|
8
|
9
|
10
|
|
L(mm)
|
13.95
|
20.30
|
26.65
|
33.00
|
39.35
|
45.70
|
52.05
|
58.40
|
64.75
|
|
S(mm)
|
6.35
|
12.70
|
19.05
|
25.40
|
31.75
|
38.10
|
44.45
|
50.80
|
57.15
|
| |
|
极 数
|
11
|
12
|
13
|
14
|
15
|
16
|
17
|
18
|
19
|
|
L(mm)
|
71.10
|
77.45
|
83.80
|
90.15
|
96.50
|
102.85
|
109.20
|
115.55
|
121.90
|
|
S(mm)
|
63.50
|
69.85
|
76.20
|
82.55
|
88.90
|
95.25
|
101.60
|
107.95
|
114.30
|
| |
|
极 数
|
20
|
21
|
22
|
23
|
24
|
25
|
26
|
27
|
28
|
|
L(mm)
|
128.25
|
134.60
|
140.95
|
147.30
|
153.65
|
160.00
|
166.35
|
|
|
|
S(mm)
|
120.65
|
127.00
|
133.35
|
139.70
|
146.05
|
152.40
|
158.75
|
|
|
|
| |
|
|
