Ethernet Cable Testers
 (以太网络测试仪



250220



250220 Coaxial BNC/TNC Cable Tester
250220 同轴线缆测试器

This basic Ethernet cable tester is one of the most affordable coaxial cable testers in the market. Use it to quickly root out shorts, open wires or other continuity problems in BNC and TNC-terminated coaxial cables. Installed cables can be tested with the included remote terminator.



250451



250451 Multi-Modular Cable Tester
250451 多功能电话测试器

The Multi-Modular Cable Tester is specifically designed to test modular-terminated (RJ45, RJ11, RJ12) for wire continuity and miswiring. It can be used to test a variety of pin configurations such as USOC 4, USOC 6 and USOC 8, no matter whether the pins are crossed or wired straight through. Moreover, with the remote terminator, you may perform all of the above tests on installed cables.



251452



251452 Enhanced Network Cable Tester
251452 加强型网路测试器

This tester quickly identifies continuity problems such as shorts, open wires, reversed pairs, crossed pairs and miswiring for 10BASE-T, 100BASE-T, EIA/TIA 568A/568B and Token Ring cables. Moreover, this tester will verify shield integrity for all STP cables. Use the included remote terminator to test installed cables.



251450E



251450/E Network Cable Tester-E
251450/E 简易多功能网络线测试器

The Network Cable Tester-E is our most affordable tester and now features the ultra convenient design with a compact remote terminator that slides into the master unit casing. Use it to quickly test network cables such as TIA568A/568B, Token Ring and 10/100Base-T cables for continuity, shorts and open wires.



251451E



251451/E Multi-Network Cable Tester-E
251451/E 多功能网路测试器

The Multi Network Cable Tester-E is specifically designed for quick testing of your network cables. Featuring high speed auto scanning for wire continuity, miswiring and shield integrity. Use this compact tester to test TIA568A/568B, Token Ring and 10/100Base-T (UTP/STP) cables. Test installed cables with the compact remote terminator that conveniently "piggy-backs" onto the master unit to prevent misplacement.



256451

中文说明

256451 NETest Remote Network Cable Tester
NETest 遥控网路线测试器

The NETest?nbsp;network cable tester is a simple but comprehensive cable tester that will diagnose wiring faults for 10BASE2 (Coax), 10BASE-T, 100BASE-Tx, EIA/TIA-586A, EIA/TIA-568B and Token Ring cables. It will not only identify wiring faults such as open wires, shorts, reversed pairs, crossed pairs, SPLIT pairs and miswiring, but also will identify up to 4 different cables from the tested end.



256551

中文说明

256551 LANtest
线缆测试类

The LANtest is the simplest and most affordable wire-mapping device for networking cables available on the market. Use it to read the actual wiring configuration for Cat5; coaxial and modular telephone cables by comparing one transmitting end to another receiving end. Cabling faults such as open wires, shorts, miswiring and crossed pairs are crystal clear with the LANtest抯 unique LED display. Perform all the above tests on installed cables with the included remote terminator.



256652/LBT

中文说明

256652/LBT LANtest Pro with tone generator
256652/LANtest Pro 遥控网路线测试器组

The LANtest Pro is a small hand-held tester that enables the user to quickly read the status of Ethernet twisted pair cables. It tests for faults such as open circuits, shorts, crossed pairs, reversed pairs and SPLIT pairs in seconds. The built-in tone generator is capable of emitting a continuous or warble tone. Use the LANtest Pro in conjunction with any cable tracer in the market to trace cables and locate faults. You'll  never lose your remote terminator again with this patented 2-in-1 design.



256652/TK

中文说明

256652/TK LANtest Pro and Probe Kit
LANtest Pro 遥控网路线测试器组

This is truly the most affordable all in one solution to cable continuity testing, fault locating and cable tracing. The LANtest Pro can be used to root out all continuity and polarity faults on Ethernet twisted pair cables. The included Probe is the perfect companion to the LANtest Pro's  toner function, allowing the user to trace cables through walls and locate faults.
