方头梅花插件 |
|
|
|
手册资料 |
|
|
公制 |
产品编号 |
梅花规格 |
配方孔 |
L |
H |
D |
重量 |
最大扭力值 |
mm |
mm |
mm |
g |
N.m |
ZQH94 |
4 |
9×12 |
17.5 |
6 |
9.6 |
40 |
7 |
ZQH95 |
5 |
9×12 |
17.5 |
6 |
10.8 |
40 |
12 |
ZQH96 |
6 |
9×12 |
17.5 |
8 |
12 |
43 |
18 |
ZQH97 |
7 |
9×12 |
17.5 |
8 |
13 |
43 |
25 |
ZQH98 |
8 |
9×12 |
17.5 |
8 |
14 |
42 |
34 |
ZQH99 |
9 |
9×12 |
17.5 |
9 |
16 |
45 |
45 |
ZQH910 |
10 |
9×12 |
17.5 |
9 |
17 |
48 |
58 |
ZQH911 |
11 |
9×12 |
17.5 |
9 |
18.5 |
47 |
72 |
ZQH912 |
12 |
9×12 |
17.5 |
12 |
20 |
54 |
89 |
ZQH913 |
13 |
9×12 |
17.5 |
12 |
22 |
53 |
105 |
ZQH914 |
14 |
9×12 |
17.5 |
12 |
23 |
52 |
125 |
ZQH915 |
15 |
9×12 |
17.5 |
12 |
24 |
54 |
145 |
ZQH916 |
16 |
9×12 |
17.5 |
13 |
26 |
56 |
160 |
ZQH917 |
17 |
9×12 |
17.5 |
13 |
27 |
55 |
160 |
ZQH918 |
18 |
9×12 |
17.5 |
13 |
28.5 |
58 |
160 |
ZQH919 |
19 |
9×12 |
17.5 |
13 |
30 |
57 |
160 |
ZQH920 |
20 |
9×12 |
17.5 |
13 |
33 |
68 |
160 |
ZQH921 |
21 |
9×12 |
17.5 |
13 |
33 |
68 |
160 |
ZQH922 |
22 |
9×12 |
17.5 |
13 |
34.5 |
73 |
160 |
ZQH923 |
23 |
9×12 |
17.5 |
13 |
36.5 |
75 |
160 |
ZQH924 |
24 |
9×12 |
25* |
13 |
37.5 |
80 |
160 |
ZQH925 |
25 |
9×12 |
25* |
13 |
40 |
80 |
160 |
ZQH927 |
27 |
9×12 |
25* |
13 |
41.5 |
80 |
160 |
ZQH930 |
30 |
9×12 |
25* |
13 |
45 |
85 |
160 |
ZQH932 |
32 |
9×12 |
25* |
13 |
47.5 |
85 |
160 |
ZQH936 |
36 |
9×12 |
30* |
13 |
52 |
90 |
160 |
ZQH941 |
41 |
9×12 |
35* |
13 |
61 |
90 |
160 |
ZQH146 |
6 |
14×18 |
25 |
11 |
13 |
95 |
18 |
ZQH147 |
7 |
14×18 |
25 |
11 |
14 |
95 |
25 |
ZQH148 |
8 |
14×18 |
25 |
11 |
16 |
95 |
34 |
ZQH149 |
9 |
14×18 |
25 |
11 |
16 |
95 |
45 |
ZQH1410 |
10 |
14×18 |
25 |
11 |
16 |
95 |
58 |
ZQH1411 |
11 |
14×18 |
25 |
11 |
18.5 |
115 |
75 |
ZQH1412 |
12 |
14×18 |
25 |
11 |
21.5 |
125 |
89 |
ZQH1413 |
13 |
14×18 |
25 |
11 |
21.5 |
125 |
105 |
ZQH1414 |
14 |
14×18 |
25 |
11 |
23 |
124 |
125 |
ZQH1415 |
15 |
14×18 |
25 |
11 |
24 |
123 |
150 |
ZQH1416 |
16 |
14×18 |
25 |
12 |
26 |
128 |
175 |
ZQH1417 |
17 |
14×18 |
25 |
12 |
27 |
127 |
200 |
ZQH1418 |
18 |
14×18 |
25 |
12 |
28.5 |
133 |
230 |
ZQH1419 |
19 |
14×18 |
25 |
12 |
30.5 |
138 |
260 |
ZQH1420 |
20 |
14×18 |
25 |
15 |
33 |
148 |
290 |
ZQH1421 |
21 |
14×18 |
25 |
15 |
33 |
148 |
330 |
ZQH1422 |
22 |
14×18 |
25 |
15 |
34.5 |
154 |
360 |
ZQH1424 |
24 |
14×18 |
25 |
15 |
37.5 |
153 |
360 |
ZQH1425 |
25 |
14×18 |
25 |
15 |
40 |
160 |
360 |
ZQH1426 |
26 |
14×18 |
25 |
16 |
41.5 |
160 |
360 |
ZQH1427 |
27 |
14×18 |
25 |
16 |
41.5 |
160 |
360 |
ZQH1428 |
28 |
14×18 |
25 |
16 |
45 |
165 |
360 |
ZQH1429 |
29 |
14×18 |
25 |
16 |
45 |
165 |
360 |
ZQH1430 |
30 |
14×18 |
25 |
16 |
45 |
165 |
360 |
ZQH1431 |
31 |
14×18 |
25 |
16 |
47.5 |
168 |
360 |
ZQH1432 |
32 |
14×18 |
25 |
16 |
47.5 |
168 |
360 |
ZQH1433 |
33 |
14×18 |
30* |
16 |
50 |
190 |
360 |
ZQH1434 |
34 |
14×18 |
30* |
16 |
51 |
190 |
360 |
ZQH1435 |
35 |
14×18 |
30* |
16 |
52 |
190 |
360 |
ZQH1436 |
36 |
14×18 |
30* |
16 |
54 |
196 |
360 |
ZQH1437 |
37 |
14×18 |
30* |
16 |
55 |
196 |
360 |
ZQH1438 |
38 |
14×18 |
35* |
16 |
57 |
210 |
360 |
ZQH1441 |
41 |
14×18 |
35* |
16 |
61 |
215 |
360 |
ZQH1442 |
42 |
14×18 |
35* |
16 |
63 |
215 |
360 |
ZQH1445 |
45 |
14×18 |
40* |
16 |
67 |
220 |
360 |
ZQH1446 |
46 |
14×18 |
40* |
16 |
68 |
225 |
360 |
ZQH1447 |
47 |
14×18 |
40* |
16 |
68.5 |
225 |
360 |
ZQH1450 |
50 |
14×18 |
40* |
16 |
70 |
230 |
360 |
ZQH1455 |
55 |
14×18 |
45* |
16 |
76 |
250 |
360 |
ZQH1460 |
60 |
14×18 |
45* |
16 |
84 |
255 |
360 |
ZQH1465 |
65 |
14×18 |
50* |
16 |
90 |
265 |
360 |
ZQH1470 |
70 |
14×18 |
55* |
16 |
96 |
270 |
360 |
ZQH1475 |
75 |
14×18 |
60* |
16 |
100 |
285 |
360 |
ZQH1480 |
80 |
14×18 |
65* |
16 |
108 |
310 |
360 |
ZQH2424 |
24 |
24×32 |
35 |
25 |
65 |
880 |
1200 |
ZQH2427 |
27 |
24×32 |
35 |
25 |
68 |
910 |
1200 |
ZQH2430 |
30 |
24×32 |
35 |
25 |
72 |
945 |
1200 |
ZQH2432 |
32 |
24×32 |
35 |
25 |
74 |
961 |
1200 |
ZQH2434 |
34 |
24×32 |
35 |
25 |
76 |
977 |
1200 |
ZQH2436 |
36 |
24×32 |
40* |
25 |
80 |
1075 |
1200 |
ZQH2438 |
38 |
24×32 |
40* |
25 |
80 |
1053 |
1200 |
ZQH2441 |
41 |
24×32 |
45* |
25 |
80 |
1059 |
1200 |
ZQH2446 |
46 |
24×32 |
45* |
25 |
84 |
1074 |
1200 |
ZQH2450 |
50 |
24×32 |
50* |
25 |
98 |
1315 |
1200 |
ZQH2455 |
55 |
24×32 |
55* |
25 |
105 |
1533 |
1200 |
ZQH2460 |
60 |
24×32 |
60* |
25 |
110 |
1642 |
1200 |
ZQH2465 |
65 |
24×32 |
65* |
25 |
128 |
1900 |
1200 |
ZQH2470 |
70 |
24×32 |
65* |
25 |
128 |
1915 |
1200 |
ZQH2727 |
27 |
27×36 |
50 |
28 |
68 |
1190 |
3000 |
ZQH2730 |
30 |
27×36 |
50 |
28 |
70 |
1190 |
3000 |
ZQH2731 |
31 |
27×36 |
50 |
28 |
70 |
1213 |
3000 |
ZQH2732 |
32 |
27×36 |
50 |
28 |
70 |
1213 |
3000 |
ZQH2734 |
34 |
27×36 |
50 |
28 |
75 |
1235 |
3000 |
ZQH2736 |
36 |
27×36 |
50 |
28 |
75 |
1225 |
3000 |
ZQH2738 |
38 |
27×36 |
50 |
28 |
80 |
1263 |
3000 |
ZQH2741 |
41 |
27×36 |
50 |
28 |
80 |
1265 |
3000 |
ZQH2746 |
46 |
27×36 |
50 |
28 |
86 |
1270 |
3000 |
ZQH2750 |
50 |
27×36 |
50 |
28 |
98 |
1603 |
3000 |
ZQH2755 |
55 |
27×36 |
55* |
28 |
105 |
1771 |
3000 |
ZQH2760 |
60 |
27×36 |
60* |
28 |
110 |
1874 |
3000 |
ZQH2765 |
65 |
27×36 |
60* |
28 |
118 |
2050 |
3000 |
ZQH2770 |
70 |
27×36 |
65* |
28 |
128 |
2322 |
3000 |
ZQH2775 |
75 |
27×36 |
75* |
28 |
138 |
2600 |
3000 |
ZQH2780 |
80 |
27×36 |
80* |
28 |
148 |
2900 |
3000 |
*为特殊规格,需要按公式调整扭力值 |
英制 |
产品编号 |
梅花 规格 |
配方孔 |
L |
H |
D |
重量 |
最大扭力值 |
mm |
mm |
mm |
g |
N.m |
ZQYH98 |
1/4 " |
9×12 |
17.5 |
8 |
13 |
43 |
25 |
ZQYH910 |
5/16 " |
9×12 |
17.5 |
8 |
14 |
42 |
34 |
ZQYH912 |
3/8 " |
9×12 |
17.5 |
9 |
17 |
48 |
58 |
ZQYH914 |
7/16 " |
9×12 |
17.5 |
9 |
18.5 |
47 |
72 |
ZQYH916 |
1/2 " |
9×12 |
17.5 |
12 |
22 |
53 |
105 |
ZQYH918 |
9/16 " |
9×12 |
17.5 |
12 |
23 |
52 |
125 |
ZQYH920 |
5/8 " |
9×12 |
17.5 |
13 |
26 |
56 |
160 |
ZQYH922 |
11/16 " |
9×12 |
17.5 |
13 |
28.5 |
58 |
160 |
ZQYH924 |
3/4 " |
9×12 |
17.5 |
13 |
30 |
57 |
160 |
ZQYH926 |
13/16 " |
9×12 |
17.5 |
13 |
33 |
68 |
160 |
ZQYH928 |
7/8 " |
9×12 |
17.5 |
13 |
34.5 |
73 |
160 |
ZQYH1416 |
1/2 " |
14×18 |
25 |
11 |
21.5 |
125 |
105 |
ZQYH1418 |
9/16 " |
14×18 |
25 |
11 |
24 |
123 |
150 |
ZQYH1420 |
5/8 " |
14×18 |
25 |
12 |
26 |
128 |
175 |
ZQYH1422 |
11/16 " |
14×18 |
25 |
12 |
28.5 |
133 |
230 |
ZQYH1424 |
3/4 " |
14×18 |
25 |
12 |
30.5 |
138 |
260 |
ZQYH1426 |
13/16 " |
14×18 |
25 |
15 |
33 |
148 |
330 |
ZQYH1428 |
7/8 " |
14×18 |
25 |
15 |
34.5 |
154 |
360 |
ZQYH1430 |
15/16 " |
14×18 |
25 |
15 |
37.5 |
153 |
360 |
ZQYH1432 |
1 " |
14×18 |
25 |
15 |
40 |
160 |
360 |
ZQYH1434 |
1
1/16
" |
14×18 |
25 |
16 |
41.5 |
160 |
360 |
ZQYH1436 |
1
1/8
" |
14×18 |
25 |
16 |
45 |
165 |
360 |
ZQYH1440 |
1
1/4
" |
14×18 |
25 |
16 |
47.5 |
168 |
360 |
ZQYH1446 |
1
7/16
" |
14×18 |
30* |
16 |
54 |
196 |
360 |
ZQYH1464 |
2 " |
14×18 |
40* |
16 |
70 |
230 |
360 |
ZQYH2430 |
15/16
" |
24×32 |
35 |
25 |
65 |
880 |
1200 |
ZQYH2436 |
1
1/8
" |
24×32 |
35 |
25 |
72 |
945 |
1200 |
*为特殊规格,需要按公式调整扭力值 |
|
|
|
|
